30NV
Elevate on-land oilfield drilling with the 30NV Swivel—the pinnacle of strength. Featuring a 3" watercourse, 4,500 max PSI, and an unparalleled 600,000 lb static load capacity, this unit stands as the strongest in our lineup. Rely on the power and durability of the 30NV Swivel for your most demanding drilling applications.
LENGTH
7ft 9in.
max pressure
4,500 PSI
watercourse
3 in.
hose connection
4" Line Pipe
weight
3,960 lbs
static load
300 Tons
Packing
VR
lower connection
5-1/2" API Regular LH Box
6-5/8" Regular Saver Sub
PACKING OPTIONS
-
V-Ring Packing Assembly
APPLICATIONS
Oilfield
Deep Water Well
FEATURES
Strong load capacity
High pressure capability
BENEFITS
Long unit life
Strongest WRAM unit manufactured
Download
