Water Well
PG
SERIES
WRAM
40PG
Explore the strength of the 40PG Swivel, a compact yet powerful unit designed for deep water well applications. With a 3" watercourse, 1,500 max PSI, and an impressive 140,000 lb static load capacity, the 40PG stands out as the next smallest unit in its series, delivering reliable performance for demanding drilling operations.
LENGTH
4ft 9 in.
max pressure
1,500 PSI
watercourse
3 in.
hose connection
3" NPT RH Box
weight
347 lbs
static load
140,000 lbs
Packing
VR
lower connection
4-1/2" O.D. 8-V LH Pin
3-1/2" IF LH Pin
PACKING OPTIONS
-
V-Ring Packing Assembly
APPLICATIONS
Deep Water Well
Shallow on-land Oilfield
FEATURES
V-Ring Packing
High pressure rating
BENEFITS
Long-unit life
Rig compatibility
Download
SIMILAR swivels
SERIES
PG
Swivels
